How does 3D LED display achieve 3D effect?
If you have never encountered this kind of naked eye 3D display effect before, you may be amazed by its amazing effect. So how does JYLED’s 3D LED display realize this 3D effect, let’s reveal it.
In fact, this cool 3D effect utilizes the human eye visual difference production. One of the most common 2D to 3D way, is to add a shadow at the bottom of the plane graphics, can make the plane graphics look more three-dimensional.
Through this principle, when we use two 90 ° angle composition of the LED screen, the use of the extension with the 3D material can realize the naked eye 3D effect.
What are the benefits to you of creating a 3D LED screen?
When you decide to use a 3D LED display, it can help you realize the following benefits:
Many 3D advertising LED screens are placed in commercial centers where foot traffic converges, and with the huge size of the 3D screen itself, it can be viewed by hundreds or thousands of people at the same time when you show commercials.
JYLED 3D LED displays have excellent visual effects that can quickly increase brand awareness. Thanks to its unique 3D display effect, it can visualize your brand, thus helping your corporate brand leave a lasting impression.
3D naked eye LED display can effectively improve the viewing experience, and no matter from which angle you view it, you can enjoy realistic visual effects, which are not available in other displays.
Due to the creative layout of the naked eye 3D LED display, it is easy to fire up both online and offline and eventually make it an iconic building. The Shinjuku 3D billboard we all know is one of the most representative examples.
Different types of 3D LED displays
The 3D effect is realized by splicing indoor high-definition LED modules, so that people can feel the stunning effect of indoor 3D LED display from a close distance even indoors.
Fully waterproof outdoor 3D LED display can be adapted to any outdoor environment, and its high brightness makes the screen still visible under direct sunlight.
Billboards with 3D effects can help advertisers attract more attention from passers-by, and JYLED has helped build 3D billboards in many areas, making them popular tourist attractions.
What are the advantages of 3D LED display?
Traditional displays can only show 2D images, only 3D LED displays are able to show this unique 3D video display effect.
JYLED adopts high quality IC to manufacture 3D LED display, so that the refresh rate of the screen is up to 3840Hz or above.
As a 3D LED display source manufacturer, JYLED supports customizing various parameters of 3D LED display according to your needs.
3D LED display adopts front and rear maintenance design, no matter you are from the front, or from the back can be very convenient to maintain the screen.
JYLED 3D LED display is waterproof up to IP66, which ensures that it can be used outdoors in all kinds of rainy and snowy weather.
In addition to the regular flat installation, JYLED also provides curved installation methods to ensure that 3D LED displays can be properly installed in some non-flat scenarios.
Multiple cabinet sizes for different screen ratios
JYLED has thoughtfully prepared a variety of cabinet sizes with different ratios for you, so that when you want to splice 3D LED displays into ideal screen ratios, it can be realized very easily.
LED light-emitting technology Energy saving more than 30%
The screen of 3D LED display is composed of self-emitting LED light beads, which, together with JYLED’s unique energy-saving technology, can make the energy-saving effect of JYLED 3D LED display more than 30% energy saving compared with regular LED display.
Digital Design and Art Display
JYLED 3D LED display is the best way to help you realize digital design and art display. It uses three-dimensional effect to show people information through a giant screen, which plays a vital role in the exposure of advertising media or commercials.
And when a huge 3D screen is in front of your eyes, it can give people a lasting visual impact that no other digital media can do.
What Surprises can 3D LED Display Bring Us?
- Make your commercials stand out from the crowd!
- Once a certain topic attracts users, it will create an explosion and will be able to get a constant flow of traffic.
- It can add interactive features to give a sense of participation to many viewers.
- Deepen the customer’s impression and form an unforgettable effect.
- High degree of integration, suitable for a variety of scenes.
Supports multiple multimedia formats
Customize your own 3D LED display
3D LED display is a customized product, such as installation position, sharpness, refresh rate, etc. need to be configured according to the specific scene. Here are some suggestions for customizing your LED 3D display:
If the reserved space behind the installed scene is small, it is suitable to use the front maintenance method; if the reserved space is bigger, it is more suitable to use the rear maintenance method.
Clarity is closely related to the model of 3D display. If you want to install outdoor 3D LED display to get a clear display effect, then you can give priority to P3, P4, and if you want better cost-effective, then P5, P6 is also a good choice.
In addition to the common outdoor 3D display models, indoor 3D displays are generally used below the P2 model, in order to be able to see in close proximity can also see the realistic 3D display content.
The refresh rate determines how well the screen can be captured. Like landmarks or popular attractions, these scenes are often people need to take photos to remember, you can prioritize high refresh rate 3D LED display, The advantage of doing so is that it can help us save a large amount of 3D LED display expenses.
The above mentioned customization suggestions have a great impact on the price of the 3D LED display, if you want a cost-effective customized solution, welcome to contact us, our professional customer service team will help you to develop a perfect solution.
Where can you use 3D LED display?
Because 3D LED display is more expensive and requires a wider space, so if we often brush various social media, we will also find that most 3D LED displays are mainly found in commercial streets and shopping centers. The following are common application scenarios for 3D LED displays:
When you are shopping in the mall, if you see a realistic 3D image, your eyes will be attracted to it. 3D LED display allows you to enjoy shopping and at the same time silently keep in mind the other marketing content on the screen through this unique 3D display.
As a platform for spreading cultural knowledge, museums pay great attention to diversified teaching methods, and a number of them have used 3D display technology combined with historical artifacts, which has triggered major social media platforms.
Using 3D LED displays in exhibitions or events will not only make your exhibition stand out among many others, but also better attract the attention of exhibitors, thus gaining more cooperation opportunities.
Airports, as a modern transportation management venue, it is usually difficult to attract people’s attention with regular decorations. Only displays with high-tech manufacturing like 3D LED displays can better attract travelers’ attention and help them to beat their free time.
As the adaptive technology of 3D LED display continues to improve, the laser projection method is no longer the preferred solution for theaters. Theaters can show movies through 3D LED displays, allowing viewers to see clearer and more realistic images. When the audience wants to watch a movie next time, they will think of this 3D LED display cinema first.
How to choose the best 3D LED screen supplier?
The best 3D LED display supplier should have excellent product quality, many cooperation cases, fast delivery, and perfect after-sales service. Here are 4 points of reference for choosing the best 3D LED display supplier.
A professional 3D LED display supplier can provide you with excellent product quality. And a good quality 3D LED display can extend the service life and equalize the cost of maintenance and service needed for a long time. Secondly, it can also stabilize the relationship between customers and ensure the long-term cooperation of the project.
The best 3D LED display suppliers usually have sold a lot of 3D LED displays, so they have a lot of cooperation cases. If you can come up with many cases of cooperation, then it means that the supplier is very trustworthy.
Fast delivery is a test of the 3D LED screen supplier’s production and manufacturing capabilities. Many 3D LED display suppliers are only sales agents and cannot produce by themselves, so they should give priority to suppliers like JYLED, which integrates production, manufacturing and sales into one.
Perfect after-sales service is one of the necessary conditions for the best 3D LED display suppliers. If the after-sales service can not keep up with the customer, once the customer encounters problems, they will be in confusion and may even need to spend a lot of money to solve the after-sales problem.
- Data Sheet
- Display Projects
- Video Case
- Product Document
| Model | P2.5 | P3 | P4 | P5 | P6 | P8 | P10 |
| Usage | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor | Outdoor |
| Cabinet Size(mm) | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 | 960*960 |
| Cabinet Resolution (dot) | 384*384 | 320*320 | 240*240 | 192*192 | 160*160 | 120*120 | 96*96 |
| Scanning | 1/16S | 1/16S | 1/10S | 1/8S | 1/8S | 1/5S | 1/2S |
| Packaging Technology | SMD | ||||||
| Installation | Front/Back | ||||||
| Density(dot/㎡) | 160000 | 111111 | 62500 | 40000 | 27777 | 15625 | 10000 |
| Brightness(cd/㎡) | 5000 | 5000 | 5000-6500 | 5000-6000 | 5000-6000 | 5000 | 4000-7000 |
| Max. Power Consumption(W) | 1000 | 1000 | 900 | 800 | 800 | 800 | 1000 |
| Average Power Consumption(W) | 350 | 350 | 300 | 400 | 300 | 300 | 500 |
| Cabinet Weight (kg) | 40 | 40 | 40 | 40 | 40 | 40 | 40 |
| Cabinet Material | Iron | ||||||
| IP Rate | IP65 | ||||||
| Grayscale | 10000:1 | ||||||
| Refresh Rate(hz) | 3840 | ||||||
| Frame Change Frequency | 50/60Hz | ||||||
| Horizontal Viewing Angle | ＞140° | ||||||
| Vertical Viewing Angle | ＞140° | ||||||
| Best Viewing Distance | >2.5m | >3m | >4m | >5m | >6m | >8m | >10m |
| Input Voltage | AC110-220V | ||||||
Testimonials
3D LED display is a popular digital display among advertisers today. As it comes with a three-dimensional 3D effect, it can stand out from the crowd of advertisements.
With the help of 3D displays, ad designers are no longer limited to print ads, but have more room to play and create a variety of attractive 3D ads.
The difference between 2D and 3D lies in the difference in dimensions. 2D usually describes a flat graphic, which only has X-axis (length) and Y-axis (width), while 3D on top of that, the eye can also feel the Z-axis (height), which creates a 3D effect.
3D LED display also utilizes the visual difference of the eye, so that the eye can feel many different dimensions after, which creates a 3D stereoscopic sense of the displayed picture.
When we want to use 3D LED display to create a naked eye 3D LED advertisement, here are some details we need to know.
Choosing the right 3D LED display
The viewing distance and price of 3D LED displays vary greatly from one pixel pitch to another, especially for large outdoor applications like this one.
In order to get the best price/performance ratio for a naked eye 3D LED display, the viewing distance, size, functionality and resolution of the screen need to be accounted for in detail. It may take a lot of time, but it will save you a lot of money.
3D Content Creation
Once you have finalized all the details of the entire 3D display, the next step is to create a suitable content for the 3D screen. If you have a professional team on your side, you can consider creating the 3D content yourself; if not, you can also talk to us directly and we will create a professional 3D content for you according to your ideas.
Installation of the screen
Once you’ve purchased your 3D naked eye display from JYLED, the next step is to install it in a previously planned location. Be sure to choose a location that will cover your target audience as fully as possible in order to achieve the best possible display.
Calibration and Testing
Once the screen has been installed, import the 3D advertising material you created earlier to calibrate and test it, and double-check every part of the screen to make sure there are no malfunctions. If you find some display abnormalities during calibration or testing, please correct them in time.
Automatic playback function of the software
When you have completed the whole installation and testing process, the next step is to debug the automated playback function of the software. With such a function, you do not need to operate the 3D advertisement switching frequently, but leave the whole process to the software to complete automatically, which saves time and effort.
Regular maintenance and update
In the future, please check the 3D screen firmware and automated playback software updates regularly according to the instructions of the 3D LED display manufacturer.
In addition, do regular checkups so that the 3D LED display can always work in the best condition.
With the above steps, you can create the perfect naked eye 3D LED advertisement. Once put into use, you will get an ongoing advertising revenue.
If you are looking for a 3D LED display manufacturer with sophisticated technology and many mature 3D billboard advertising examples, then JYLED is definitely a partner you can trust. At present, we have produced multiple 3D LED displays for large supermarkets in many countries and regions.
We also provide long-term technical support services, which can enable you to continuously track from purchase to installation, as well as the subsequent screen debugging, so that you can buy with confidence and use with peace of mind.
The price of 3D LED display is mainly composed of three parts: LED display, 3D material, application scene.
LED display
3D LED displays with smaller pixel pitches (e.g. P3-P5) can cost from RMB 7,500 to over RMB 25,000 per square meter.
3D LED displays with larger pixel pitches (e.g. P5-P10) are more affordable, e.g. P5-P6 cost around RMB 4,500-6,500 per square meter and P8-P10 cost around 3,000-4,500 per square meter.
3D Material
According to the production time of 3D material, different degree of exquisite, the price varies greatly. In China, the market price for a 1-minute 3D material is between 30,000-100,000 RMB.
Application Scene
The price of outdoor 3D LED display is always higher than indoor 3D LED display, this is because outdoor 3D LED display not only needs to have IP65 protection level, but also the brightness of the LED beads is several times higher than indoor display, other aspects whether it is the cabinet, materials or accessories are not the same.
3D LED billboards are essentially creative advertising displays made using 3D LED screens. This approach breaks away from traditional flat displays, capturing attention with more realistic 3D effects to enhance advertising exposure.
This is because 3D LED displays are relatively expensive, making them more affordable for developed nations. However, developing nations like China, Saudi Arabia, and Brazil also deploy numerous 3D LED displays.
Especially for a superpower like China, although it is also a developing country, the number of 3D LED displays is second only to the United States.
Due to international internet restrictions on China, many 3D LED display projects remain inaccessible on the global web. Consequently, most 3D case studies we encounter originate from developed nations.
No, 3D content is not included with the purchase of a 3D LED display. If you require 3D content to accompany your display, please consult our sales team in advance. Fees for 3D content production are determined by complexity and duration.
This primarily depends on your budget requirements. As a professional 3D LED display manufacturer, JYLED can produce displays of any size provided your budget allows. Based on our extensive portfolio of 3D projects, 300-800 square meters represents the mainstream choice for most advertisers.
3D LED screens are designed to deliver a naked-eye visual experience, resulting in exceptionally lifelike effects. Otherwise, so many 3D LED displays wouldn’t have become local landmarks.
If you want to buy a high-quality 3D LED display screen, then you must know some of its standards. To this end, we have listed 8 reference factors:
- Have a variety of refresh rates to choose from
- Customizable size
- Have mature 3D LED display screen cases
- Have extremely high brightness, brightness above 5000 nits
- The display screen can be perfectly integrated with the building
- Use high-quality IC and LED lamp beads
- Built-in brightness sensor, which can automatically adjust the brightness
- Have matching engineers for service support
Naked-eye 3D advertisement displays are very effective in increasing brand awareness and mass participation for commercial advertisements and enterprises.
Huge size and easy to view
Many 3D advertising LED screens are placed in popular commercial buildings, and due to the huge size of the screen itself, coupled with the traffic flow of the location, they can be viewed by hundreds or thousands of people at the same time.
Enhance Brand Value
With prominent visual images, 3D LED displays can quickly increase the value and visibility of a brand. And because the displays are so attractive, they can help a business or brand create a lasting impression.
Improved viewing experience
3D naked eye LED displays can effectively improve the viewing experience, allowing people to see the image from a different perspective and get a different and fresh feeling.
Iconic Architecture
Due to the creative format of naked eye 3D LED displays, it is easy to create an effective promotional campaign that attracts more people to the building and eventually becomes an iconic structure.
As the world’s economic powerhouse, China has the largest number of 3D LED advertising displays in the world. Due to the large number, we have selected 4 naked-eye 3D LED displays with the largest area and the highest impact to show you:
Chengdu Taikoo Li 3D billboard
We can see a huge alien sticking out its head and looking out of the screen from the picture, which is shocking. Although the movie is only 30 seconds, the performance is enough to make people breathtaking.
Yunnan Kunming 3D Billboard display
In Kunming, Yunnan Province, there is a huge 3D LED display billboard in Dongfeng Square. This naked eye 3D display billboard has an area of 2,184 square meters. From the screen, we can see a huge elephant stretching out its feet in the tropical rainforest.
Hubei Wuhan 3D display Billboard
This is a huge naked-eye 3D display billboard located on Zhongbei Road in Wuhan, Hubei Province. With an area of 1,488 square meters, it is the largest 3D LED display in Wuhan. The screen has a resolution of 8K, so it still delivers perfect picture quality during the day.
Shandong Jinan 3D display billboard
The 1,600 square meter naked eye 3D billboard near XINCC in Quancheng, Jinan, Shandong Province, is currently the largest 3D LED display in Jinan. Its realistic and stunning display effect makes pedestrians stop and take a closer look.
